Simucube 3 Sport Wheel Base

Simucube 3 Sport Wheel Base

Precision-engineered direct drive performance with 15 Nm of peak torque

Unmatched Smoothness and Realism

• Precise, smooth, and detailed force feedback (15 Nm)
• Industrial-grade SPM servo motor engineered exclusively for Simucube
• Enhanced telemetry-based effects including ABS, RPM, and road texture
• Re-engineered control algorithm for maximum accuracy and silent operation
• Frictionless setup with front and bottom mounting and versatile adapters

Professional-Grade Engineering

• Shares the same advanced features as the Simucube 3 Pro model
• Benchmark direct drive performance in a lighter and more compact design
• Powered by the new-generation SPM motor with ultra-smooth response
• Built to deliver enduring reliability and consistent performance

Product Parameters

• Max Torque: 15 Nm
• Motor: Direct Drive optimized SPM motor
• Angle Sensor: 23-bit absolute (8,000,000 steps)
• Mounting: Front and Bottom
• Warranty: 3 years

Technical Details

Dimensions

• Wheel Base: 135 × 135 × 278 mm
• Package Dimensions: 190 × 300 × 390 mm
• Mounting Hole Pattern DIA: 135 mm and 78.4 mm
• Flange Centering Feature DIA: 110 mm
• Weight: 8.7 kg

Specifications

• Motor Type: Direct Drive optimized SPM motor
• Max Torque: 15 Nm
• Angle Sensor: 23-bit absolute (8,000,000 steps)
• Power Supply: 280 W
• Warranty: 3 years

What’s Included?

• 1 × Simucube 3 Sport Wheel Base
• 1 × Power Adapter
• 1 × RJ45 Cable
• 1 × AC Power Cord
• 1 × Quick Start Guide
• 1 × Control Box
• Fasteners Kit:
• 4 × M8 Washer
• 4 × M6 Washer
• 2 × M5 Washer
• 4 × M8 × 35 Allen Head Bolt
• 4 × M8 × 30 Allen Head Bolt
• 2 × M5 × 30 Allen Head Bolt
• 4 × M6 × 16 Allen Head Bolt
• 2 × M5 T-slot Nut (8 mm slot)
• Does NOT include: Link Quick Release for Simucube 3, Simucube Link Hub

Compatibility

• Link Quick Release for Simucube 3
• One Simucube Link Hub is required to operate.
• For multiple Link Hub devices such as Simucube 3 and ActivePedals, please use the Teltonika Ethernet Switch.
